Brass SC Cable Gland

Brass SC Cable Gland
Brass SC Cable Gland
Product Code : MBC018
Brand Name : Metaford
Price And Quantity
  • Minimum Order Quantity
  • 2500
  • Unit of Measure
  • Piece/Pieces
Product Description
We are a trusted name among the manufacturers of Brass SC Cable Gland to our highly valued clients. It is sturdily built using utmost quality material and advanced machinery at our unit under the vigilance of our professionals. Owing to its fine finishing, corrosion resistance, dimensional accuracy, unmatched built, high durability and sturdy nature, this Brass SC Cable Gland is highly demanded and applauded among that of our competitors. We check this prior to dispatch to make sure that it stands free from any quality compromise.


Material

  • Brass BS 2874 Cz121 Pb3

Finish

  • Nickel plated-Standards.
  • Tin/Cadmium/Chrome also available

Threads

  • Metric-Standards , ET/BSC/PG/NPT/BSP also available

Sealing Ring

  • Natural Rubber

Application

Single Compression Glands are weather proof and dust proof (IP-60) which can be used in normal climatic condition. Also when protected by PVC shrouds it can be used in corrosive atmosphere.

These glands are available in different sizes and are suitable for all cables upto 1000 sq. mm. and control cables upto 61 cores.

Fitting sequence

  • Insert Part No.5, 3, & 4 Respectively on the Outer Sheath of the cable Before Exposing the Armour,
  • After Removing Over Sheath of the Cable, Insert Part No. 3, Now Exposed Armour, Size the Armour length According to washer & band the same,
  • Again Insert Part No.3 & place on the Bended Washer, so as to Secured armour safely.
  • Insert Part No.2 on Inner Sheath, Than tight Part No.2 with Part No.5,
  • Finally Apply the full fitted Gland in the Enclosure with Entry Thread provided,
  • the Enclosure does not have thread than tight the gland with the part No.1 provided

Brass Single Compression Cable Gland  (HEAVY DUTY )

Suitable Cable  D1  D2 D3 D4 D5 L1
Overall Dia Nipple Entry Threads in Metrics  Dia. Dia. (A/F) (A/C) Length
From To mm Ø mm Ø mm mm mm mm
9 12 16 x 1.5 12 16 22 25.5 9
12 15 16 x 1.5 12 18.5 25 29 9
12 15 20 x 1.5 15 18.5 25 29 9
15 18 20 x 1.5 15 24 30 34.5 9.5
16 20 25 x 1.5 20.5 24 31.5 36 9.5
20 24 25 x 1.5 20.5 28.5 35 40 10
24 28 32 x 1.5 27 33 40 46 12
28 32 40 x 1.5 34 37 46 53 12
33 37 40 x 1.5 34 41 50 57.5 12
37 42 50 x 1.5 44 47 58 67 13
43 48 50 x 1.5 44 52 65 75 13
49 54 63 x 1.5 55 61.5 73 84 14
55 60 63 x 1.5 55 65 77 89 14
61 66 75 x 1.5 68 71 85 98 15
67 72 75 x 1.5 67 76 90 104 15
73 78 82 x 1.5 73 82 97 112 17
79 84 90 x 1.5 81 91 108 124 19
84.5 92 100 x 1.5 91 98 117 135 20
93 100 110 x 1.5 100 107 127 146 25
101 115 125 x 1.5 113 118 142 164 25
Trade Information
  • Payment Terms
  • Cheque, Letter of Credit (L/C), Telegraphic Transfer (T/T), Paypal
  • Supply Ability
  • 30000 Pieces Per Month
  • Sample Available
  • Yes
  • Sample Policy
  • Free samples available with shipping and taxes paid by the buyer
  • Packaging Details
  • Export Standard Packing
  • Main Export Market(s)
  • Asia, Middle East, Africa
  • Main Domestic Market
  • All India
